Used to spread and hold conductors aside at mid-span, for increased working space, when relocating poles..

Since it is attached to the conductor through the roller head, it may be pulled by the ground man into position by a hand line or rope block attached to the butt ring.

The roller head suitable for conductors of up to 605 kcmi ACSR (Diam. 24 mm - 0.95"t approx.).

The Roller Link Stick is composed of a 32 mm (1-1/4") Ritzglas® pole and cooper alloy head and roller, assembled to a threaded pin, for jaw opening and closing operations, to secure conductors.

Ferrules are made of heat-treated aluminum alloy. Butt-swivels - for attaching rope blocks or hand lines - are forged of high quality steel and rotate freely on ball thrust bearing.

Roller Link Stick
