Type

Detail

FLV06052-1

1.0 x 1.0 m (3.3 x 3.3 ft) module, with cast aluminium connections, built with diam. 38 mm (1.5") Ritzglas® poles, with sliding-proof rungs and counter pins for locking
Approx. Weight. 15.43 lb

FLV09091-1

1.0 x 2.0 m (3.3 x 6.5 ft) module, with cast aluminum connections, built with diam. 38 mm (1.5") Ritzglas® poles, with sliding-proof rungs and counter pins for locking
Approx. Weight. 26.90 lb

FLV13916-1

1.0 x 2.0 m (3.3 x 6.5 ft) module, with cast aluminum connections, built with diam. 38 mm (1.5") Ritzglas® poles, with sliding-proof rungs and counter pins for locking. Also, it is provided with 5 top pins, for non-conventional
arrangements
Approx. Weight. 29.98 lb

FLV16241-1

Side Crosspiece. Built with diam. 38 mm x 1.0 m (diam. 1.5" x 3.3 ft) Ritzglas® poles and cast aluminum connections. Intended for closing and locking the
modules of 1.0 x 1.0 m (3.3 x 3.3 ft) and 1.0 x 2.0 m (3.3 x 6.5 ft) scaffolds bases.
Approx. Weight. 1.96 lb

FLV16241-2

Side Crosspiece. Built with diam. 38 mm x 1.0 m (diam. 1.5" x 3.3 ft) Ritzglas® poles and cast aluminum connections. Intended for closing and locking the
modules of 1.0 x 1.0 m (3.3 x 3.3 ft) and 1.0 x 2.0 m
(3.3 x 6.5 ft) scaffolds bases.
Approx. Weight. 4.84 lb

FLV16241-3

Side Crosspiece. Built with diam. 38 mm x 1.0 m (diam. 1.5" x 3.3 ft) Ritzglas® poles and cast aluminum connections. Intended for closing and locking the
modules of 1.0 x 1.0 m (3.3 x 3.3 ft) and 1.0 x 2.0 m (3.3 x 6.5 ft) scaffolds bases.
Approx. Weight. 3.31 lb

FLV16241-4

Side Crosspiece. Built with dia. 38 mm x 1.0 m (dia. 1.5" x 3.3 ft) Ritzglas® poles and cast aluminum connections. Intended for closing and locking the modules of 1.0 x 1.0 m (3.3 x 3.3 ft) and 1.0 x 2.0 m (3.3 x 6.5 ft) scaffolds bases.
Approx. Weight. 4.41 lb

FLV16241-5

Side Crosspiece. Built with dia. 38 mm x 1.0 m (dia. 1.5" x 3.3 ft) Ritzglas® poles and cast aluminum connections. Intended for closing and locking the
modules of 1.0 x 1.0 m (3.3 x 3.3 ft) and 1.0 x 2.0 m (3.3 x 6.5 ft) scaffolds bases.
Approx. Weight. 5.29 lb

FLV17444-1

Platform composed of four fiberglass boards with sliding-proof surface treatment. This model is only used when assembling the 2.0 x 1.0 m (6.5 x 3.3 ft) scaffold base.
Approx. Weight. 58.20 lb

FLV17444-2

Platform composed of eight fiberglass boards with sliding-proof surface treatment. This model is only used when assembling the 2.0 x 2.0 m (6.5 x 6.5 ft) scaffold base.
Approx. Weight. 243.83 lb

FLV17444-3

Platform composed of two fiberglass boards with sliding-proof surface treatment. This model is only used when assembling the 1.0 x 1.0 m (3.3 x 3.3 ft) scaffold base.
Approx. Weight. 29.10 lb

FLV04803-3

Platform composed of two fiberglass boards with sliding-proof surface treatment. This model is only used when assembling the 1.0 x 1.0 m (3.3 x 3.3 ft) scaffold base.
Approx. Weight. 2.54 lb

RM1895-3

Platform composed of two fiberglass boards with sliding-proof surface treatment. This model is only used when assembling the 1.0 x 1.0 m (3.3 x 3.3 ft) scaffold base.
Approx. Weight. 0.15 (m each)

FLV11630-1

Set of individual wheels for the 1.0 x 1.0 m (3.3 x 3.3 ft) scaffold displacement, provided with stabilizers and two steel rods, for spacing and locking.
Approx. Weight. 238.98 lb

FLV11630-2

Set of individual wheels for the 2.0 x 1.0 m (6.5 x 3.3 ft) scaffold displacement, provided with stabilizers and two steel rods, for spacing and locking.
Approx. Weight. 238.98 lb

FLV11630-3

Set of individual wheels for the 2.0 x 2.0 m (6.5 x 6.5 ft) scaffold displacement, provided with stabilizers and two steel rods, for spacing and locking.
Approx. Weight. 243.83 lb

FLV11658-1

Set hot dip galvanized rails (three pairs of 2 m - 6.5 ft -long rails each). These rails are interconnected using locking pins and correspondent spacing steel rods. It’s been designed to ease the horizontal displacement of the 1.0 x 1.0 m (3.3 x 3.3 ft) and 2.0 x 1.0 m (6.5 x 3.3 ft) scaffolds, on uneven surfaces at substations.
Approx. Weight.227.30 lb

FLV11658-2

Set hot dip galvanized rails (three pairs of 2 m - 6.5 ft - long rails each). These rails are interconnected using locking pins and correspondent spacing steel rods. It’s been designed to ease the horizontal displacement of the 1.0 x 1.0 m (3.3 x 3.3 ft) and 2.0 x 2.0 m (6.5 x 6.5 ft) scaffolds, on uneven surfaces at substations.
Approx. Weight. 229.94 lb

Type

Details

FLV16238-1

1.0 x 1.2 m (3.3 x 4 ft) Guard module with cast aluminum connections, of same insulating and mechanical characteristics as those of the regular
modules, to be used as an additional body protection at the level the platform will be assembled.
Approx. Weight. 18.30 lb

FLV17496-1

2.0 x 1.2 m (6.5 x 4 ft) Guard module with cast aluminum connections, of same insulating and mechanical characteristics as those of the regular
modules, to be used as an additional body protection at the level the platform will be assembled.
Approx. Weight. 30.42 lb

FLV16237-1

Intermediary Crosspiece
Built with dia. 38 mm x 1.0 m (dia. 1.5" x 3.3 ft) Ritzglas® poles and clamps at the ends, used to box up the guard modules of 2.0 x 1.0 m (6.5 x 3.3 ft) and 1.0 x 1.0 m (3.3 x 3.3 ft) platforms. It is assembled at 0.7 m (2.3 m) above the platform for increased safety.
Approx. Weight. 5.07 lb

FLV16237-2

Intermediary Crosspiece
Built with dia. 38 mm x 2.0 m (dia. 1.5" x 6.5 ft) Ritzglas® poles and clamps at the ends, used to box up the guard modules of 2.0 x 2.0 m (6.5 x 6.5 ft) platforms. It is assembled at 0.7 m (2.3 ft) above the platform for increased safety.
Approx. Weight.6.39 lb

FLV16241-6

Side Crosspiece for Guard Modules

Built with dia. 38 mm x 1.0 m (dia. 1.5" x 3.3 ft) Ritzglas® poles and cast aluminum connections. Intended for
closing and locking the guard modules of 1.0 x 1.0 (3.3 x 3.3 ft) and 1.0 x 2.0m   (3.3 x 6.5 ft) scaffolds.
Approx. Weight. 1.96 lb

FLV16241-7

Side Crosspiece for Guard Modules

Built with dia. 38 mm x 2.0 m (dia. 1.5" x 6.5 ft) Ritzglas® poles and cast aluminum connections. Intended for closing and locking the guard modules of 2.0 x 2.0 m (6.5 x 6.5 ft) scaffolds.
Approx. Weight. 4.48 lb

FLV14342-1

Fiberglass Safety Baseboard
To be clamped onto the base of 1.0 x 1.0 m (3.3 x 3.3 ft) platforms, to prevent tools or components from dropping accidentally.
Approx. Weight. 17.64 lb

FLV14342-2

Fiberglass Safety Baseboard
To be clamped onto the base of 2.0 x 1.0 m (6.5 x 3.3 ft) platforms, to prevent tools or components from dropping accidentally.
Approx. Weight. 27.12 lb

FLV14342-3

Fiberglass Safety Baseboard
To be clamped onto the base of 2.0 x 2.0 m (6.5 x 6.5 ft) platforms, to prevent tools or components from dropping accidentally.

Approx. Weight. 35.37 lb

Type

Details

FLV09012-1

0.50 x 1.0 m (1.5 x 3.3 ft) Reduced Height Module
With the same insulating and mechanical characteristics as the other modules. Enables assemblies to intermediate heights, suiting workers to a better working position
Approx. Weight. 10.80 lb

ESC15051-1

0.50 x 1.0 m (1.5 x 3.3 ft) Reduced Height Module
With the same insulating and mechanical characteristics as the other modules. Enables assemblies to intermediate heights, suiting workers to a better working position
Approx. Weight. 1.54 lb

ESC15051-2

Guying Poles
Built with a dia. 3/8” x 2.0 m (6.5 ft) Ritzglas® rod, with one aluminum fork fitting at one end and one eye-ring at the other, making it possible to connect two poles, if necessary. Load capacity: 500 daN (1102 lb)
Approx. Weight. 1.21 lb

ESC15051-3

Guying Poles
Built with a dia. 3/8” x 2.0 m (6.5 ft) Ritzglas® rod, with one aluminum fork fitting at one end and one eye-ring at the other, making it possible to connect two poles, if necessary. Load capacity: 500 daN (1102 lb)
Approx. Weight. 0.88 lb

FLV17648-1

Guying Poles
Built with a dia. 3/8” x 2.0 m (6.5 ft) Ritzglas® rod, with one aluminum fork fitting at one end and one eye-ring at the other, making it possible to connect two poles, if necessary. Load capacity: 500 daN (1102 lb)
Approx. Weight. 0.88 lb

FLV15444-1

Removable Rung Assembly to be attached onto the side of the modules, to provide additional rungs where originally there is no rung
Approx. Weight. 8.16 lb

FLV18169-1

Tools lifting Gin
Attached to the far right module to ease lifting of heavy components. Axial angle of approx. 40° allows both right and left gins to be used simultaneously to lift materials with larger dimensions.
Max. working load: 60 daN (132 lb)
Approx. Weight. 4.41 lb

FLV18169-2

Tools lifting Gin
Attached to the far left module to ease lifting of heavy components. Max. working load: 60 daN (132 lb)
Approx. Weight. 4.41 lb

FLV18375-1

Fiberglass Tool Box
Provides safe, quick and practical storage of tools, during maintenance works. Made of fiberglass and fitted with two cast aluminum fasteners, for attachment to the module Dimensions: 0.62 x 0.22 x 0.20 m (2.0 x 0.7 x 0.6 ft)
Approx. Weight. 10.80 lb

FLV23916-1

Galvanized steel stake made of semi-circled rod to be used as a guy rope for scaffolds.
Approx. Weight. 3.50 lb

RC402-0288

Micro Tester
A micro-ammeter used to monitor leakage currents, when carrying out field electrical tests on the scaffold.
It features a 0 to 200 uA scale and is provided with fasteners, connection cable and storage case.
Approx. Weight. 7.19 lb
