These covers are used for protection on structures where there are Fuse- Switches or Knife-Switches and can be installed with Rubber Glove or Hot Stick Methods.

The Fuse-Switch Cover RC406-0009 is held in place with a pin that slips behind the insulator and is supported by the metallic bracket of the switch.

The Knife-Switch Covers (COB28494-1) are installed by involving the two sheds of the insulator, onto which it is fixed by pressure.

The knife-switch housing cover (COB13345-1) is used for insulating protection between the housing of the knife-switch and the energized parts during the installation and removal of the jumper or other works performed on the switch. Designed for systems of 15 and 23 kV, they are built with 2 plain sheets, which after being partially open envelop the base of the  insulators and are locked with insulating nuts.

FUSE-SWITCH AND KNIFE-SWITCH COVERS
