Fuse Link

Description

The Fuse Links are essential parts of a distribution system of electricity, impeding the occurrence of short-circuit and over-current that can cause serious damage to the power grid. The Indel Bauru can produce the following types: H, K, T, EF HXO e HYO, STD, IS, DI, QI and Open Link. In according to following national and international standards: NBR 7282:2011, IEC 60282-2, ANSI C37.41, ANSI C37.42 and NEMA PUB. SG-2.

» Amp: 1A – 200A
» Voltage: 11kV – 38kV
» Standards: NBR 7282:2011, ANSI C37-41, ANSI C37-42 and IEC 060282-2
» Interrupting Capacity proven.
